# (a) Rock’s Speed Just Before It Falls Into the River
| Step | Derivation/Formula | Reasoning |
|---|---|---|
| 1 | [katex]v_i = 20 \, \text{m/s}[/katex] | Initial velocity of the rock thrown upward. |
| 2 | [katex]h = -42 \, \text{m}[/katex] | Final displacement of the rock from the point of throw to the river is -42 meters (negative since it’s downward). |
| 3 | [katex]v_f^2 = v_i^2 + 2a h[/katex] | Using the kinematic equation to find the final velocity, where [katex]v_i[/katex] is initial velocity, [katex]v_f[/katex] is final velocity, [katex]a[/katex] is acceleration and [katex]h[/katex] is displacement. |
| 4 | [katex]a = -9.8 \, \text{m/s}^2[/katex] | Acceleration due to gravity (negative since it’s downward). |
| 5 | [katex]v_f^2 = (20 \, \text{m/s})^2 + 2(-9.8 \, \text{m/s}^2)(-42 \, \text{m})[/katex] | Substitute the known values into the kinematic equation. |
| 6 | [katex]v_f^2 = 400 + 823.2[/katex] | Calculate the expression inside the equation. |
| 7 | [katex]v_f = \sqrt{1223.2} \, \text{m/s}[/katex] | Taking the square root of both sides to solve for the final velocity [katex]v_f[/katex]. |
| 8 | [katex]v_f \approx 35 \, \text{m/s}[/katex] | Final speed of the rock just before it falls into the river. |
# (b) Time Taken for the Rock to Strike the River
| Step | Derivation/Formula | Reasoning |
|---|---|---|
| 1 | [katex]v_f = v_i + a t[/katex] | Using the first kinematic equation to solve for time [katex]t[/katex], where [katex]v_f[/katex] is final velocity, [katex]v_i[/katex] is initial velocity, [katex]a[/katex] is acceleration, and [katex]t[/katex] is time. |
| 2 | [katex]v_f = -35 \, \text{m/s}[/katex] | Since the rock is falling downward, take final velocity [katex]v_f[/katex] as negative. |
| 3 | [katex]-35 \, \text{m/s} = 20 \, \text{m/s} + (-9.8 \, \text{m/s}^2) t[/katex] | Substitute the known values into the time equation. |
| 4 | [katex]-35 = 20 – 9.8 t[/katex] | Simplify the equation. |
| 5 | [katex]-55 = -9.8 t[/katex] | Combine like terms. |
| 6 | [katex]t = \frac{55}{9.8}[/katex] | Isolate [katex]t[/katex] by dividing both sides of the equation by -9.8. |
| 7 | [katex]t \approx 5.6\, \text{s}[/katex] | Solving for time gives approximately 5.6 seconds. |
Just ask: "Help me solve this problem."
A car moves forward at a steady \( 10 \) \( \text{m/s} \) for \( 5 \) \( \text{s} \). The driver slams the brakes and brings it to rest in \( 2 \) \( \text{s} \). Without waiting, the driver immediately accelerates backward (negative velocity) for \( 3 \) \( \text{s} \) until reaching \( 8 \) \( \text{m/s} \) in reverse. Draw the velocity vs. time graph.
The figure shows the velocity-versus-time graph for a basketball player traveling up and down the court in a straight-line path. Find the displacement of the player…
A truck is traveling at 35 m/s when the driver realizes the truck as no breaks. He sees a ramp off the road, inclined at 20°, and decides to go up it to help the truck come to a stop. How far does the truck travel before coming to a stop (assume no friction).
A horizontal spring with spring constant 162 N/m is compressed 50 cm and used to launch a 3 kg box across a frictionless, horizontal surface. After the box travels some distance, the surface becomes rough. The coefficient of kinetic friction of the box on the rough surface is 0.2. Find the total distance the box travels before stopping.
A car accelerates from rest with an acceleration of \( 3.5 \, \text{m/s}^2 \) for \( 10 \, \text{s} \). After this, it continues at a constant speed for an unknown amount of time. The driver notices a ramp \( 50 \, \text{m} \) ahead and takes \( 0.6 \, \text{s} \) to react. After reacting, the driver hits the brakes, which slow the car with an acceleration of \( 7.2 \, \text{m/s}^2 \). Unfortunately, the driver does not stop in time and goes off the \( 3 \, \text{m} \) high ramp that is angled at \( 27^\circ \).
