| Step | Derivation/Formula | Reasoning |
|---|---|---|
| 1 | \[N = 1.15\,mg\] | The apparent weight is the normal force \(N\). A 15% increase means \(N\) is 1.15 times the true weight \(mg\). |
| 2 | \[N \;{\large\gtrless}\; mg\] | On a dip, occupants feel heavier so \(N > mg\); on a hill they feel lighter so \(N < mg\). |
| 3 | \[1.15\,mg > mg\] | Because the measured normal force is larger, the car must be at the bottom of a dip (concave-up curve). |
| Step | Derivation/Formula | Reasoning |
|---|---|---|
| 1 | \[v_i = 30\;\text{m/s}\] | Given constant speed of the car. |
| 2 | \[N – mg = m\frac{v_i^2}{R}\] | At the lowest point of a dip, the net upward (center-seeking) force is the centripetal force \(m v_i^2 / R\). |
| 3 | \[1.15\,mg – mg = m\frac{v_i^2}{R}\] | Substitute \(N = 1.15\,mg\). |
| 4 | \[0.15\,mg = m\frac{v_i^2}{R}\] | Simplify the left side. |
| 5 | \[R = \frac{v_i^2}{0.15\,g}\] | Rearrange the equation to solve for the radius \(R\). |
| 6 | \[R = \frac{30^2}{0.15\times9.8}\;\text{m} = 6.1\times10^{2}\,\text{m}\] | Insert \(v_i = 30\,\text{m/s}\) and \(g = 9.8\,\text{m/s}^2\); compute the value. |
| 7 | \[\boxed{R \approx 6.1\times10^{2}\,\text{m}}\] | Final numerical result for the radius of vertical curvature. |
Just ask: "Help me solve this problem."
A car is moving up the side of a circular roller coaster loop of radius \( 12 \) \( \text{m} \). The angular velocity is \( 1.8 \) \( \text{rad/s} \) and angular acceleration is \( -0.82 \) \( \text{rad/s}^2 \). The car is at the same elevation as the center of the loop. Find the magnitude and direction (relative to the horizontal) of the acceleration.
A race car travels in a circular track of radius \( 200 \) \( \text{m} \). If the car moves with a constant speed of \( 80 \) \( \text{m/s} \),
Two satellites of equal mass, \( S_1 \) and \( S_2 \), orbit the Earth. \( S_1 \) is orbiting at a distance \( r \) from the Earth’s center at speed \( v \). \( S_2 \) orbits at a distance \( 2r \) from the Earth’s centre at speed \( \dfrac{v}{\sqrt{2}} \). The ratio of the centripetal force on \( S_1 \) to the centripetal force on \( S_2 \) is
An object of mass \( m = 3.0 \) \( \text{kg} \) is attached to one end of a string with negligible mass and length \( L = 0.80 \) \( \text{m} \). The object is released from rest at time \( t = 0 \), when the string is horizontal. At time \( t = t_1 \) the object is at the location shown in the figure, where the string is vertical. Which of the following is most nearly the magnitude of the tension in the string at time \( t = t_1 \)?
A car of mass \( M \) moves around a circularly banked curve on a freeway off-ramp. The off-ramp has a radius of curvature \( R \) and is raised to an angle \( \theta \) from the horizontal. The road is slick, and friction is negligible.
\(\text{dip}\)
\(6.1\times10^{2}\,\text{m}\)
