| Step | Derivation/Formula | Reasoning |
|---|---|---|
| 1 | $$F_{\parallel} = F\cos(\theta)$$ | The horizontal force \( F \) is resolved into a component along the inclined plane. The component along the plane is given by \( F\cos(\theta) \). |
| 2 | $$F_{g\,\parallel} = mg\sin(\theta)$$ | The gravitational force has a component down the incline given by \( mg\sin(\theta) \). |
| 3 | $$N = mg\cos(\theta)+ F\sin(\theta)$$ | The normal force \( N \) is found by resolving forces perpendicular to the incline. Gravity gives \( mg\cos(\theta) \) and the horizontal force contributes \( F\sin(\theta) \) pushing the block into the plane. |
| 4 | $$F_{f} = \mu N = \mu\left(mg\cos(\theta)+ F\sin(\theta)\right)$$ | The frictional force is given by the coefficient of friction \( \mu \) times the normal force. |
| 5 | $$m\,a = F\cos(\theta)- mg\sin(\theta)- \mu\left(mg\cos(\theta)+ F\sin(\theta)\right)$$ | Applying Newton’s second law along the incline, the net force is the sum of the component of \( F \) along the plane minus both the gravitational and frictional forces. |
| 6 | $$a = \frac{F\cos(\theta)- mg\sin(\theta)- \mu\left(mg\cos(\theta)+ F\sin(\theta)\right)}{m}$$ | This is the final expression for the block’s acceleration \( a \) up the incline in terms of \( m,\,\theta,\,\mu,\,F, \) and \( g \). |
| Step | Derivation/Formula | Reasoning |
|---|---|---|
| 1 | $$0 = F\cos(\theta)- mg\sin(\theta)- \mu\left(mg\cos(\theta)+ F\sin(\theta)\right)$$ | For the block to slide up the plane with constant velocity, the acceleration must be zero. Hence the net force along the incline is zero. |
| 2 | $$F\cos(\theta)- \mu F\sin(\theta) = mg\sin(\theta)+ \mu mg\cos(\theta)$$ | Rearrange the equation by grouping the terms involving \( F \) on the left and the gravitational terms on the right. |
| 3 | $$F \left(\cos(\theta)- \mu \sin(\theta)\right) = mg\left(\sin(\theta)+ \mu\cos(\theta)\right)$$ | Factor out \( F \) on the left-hand side and \( mg \) on the right-hand side for clarity. |
| 4 | $$F = \frac{mg\left(\sin(\theta)+ \mu\cos(\theta)\right)}{\cos(\theta)- \mu\sin(\theta)}$$ | Solve the equation for \( F \) by dividing both sides by \(\cos(\theta)- \mu \sin(\theta)\). |
| 5 | $$\cos(\theta)- \mu\sin(\theta)> 0 \quad \Longrightarrow \quad \tan(\theta) < \frac{1}{\mu}$$ | For \( F \) to be physically meaningful (i.e., a positive real number), the denominator must be positive. Rearranging the inequality yields the condition \( \tan(\theta) < \frac{1}{\mu} \). |
| 6 | $$\boxed{F = \frac{mg\left(\sin(\theta)+ \mu\cos(\theta)\right)}{\cos(\theta)- \mu\sin(\theta)}}$$ | This is the final expression for the magnitude of the applied horizontal force required to make the block slide with a constant velocity, including the physical condition on \( \theta \) and \( \mu \). |
