Intermediate
Mathematical
MCQ

Consider a solid uniform sphere of radius \(R\) and mass \(M\) rolling without slipping. Which form of its kinetic energy is larger, translational or rotational?

Advanced
Mathematical
GQ

A \(3800 \, \text{kg}\) open railroad car coasts along with a constant speed of \(8.60 \, \text{m/s}\) along a level track. Snow begins to fall vertically and fills the car at a rate of \(3.50 \, \text{kg/min}\). Ignoring friction with the tracks, what is the speed of the car after \(90 \, \text{min}\)?

Intermediate
Mathematical
MCQ

A cube of side length \( s \) rests on the bottom surface of a container of fluid. The fluid is at a height \( y \) above the bottom of the tank. The fluid has density \( \rho \) and the atmospheric pressure is \( P_{\text{atm}} \).

Which of the following expressions is equal to the absolute pressure exerted by the fluid on the top surface of the cube?

Intermediate
Mathematical
FRQ

A firecracker in a coconut blows the coconut into three pieces. Two pieces of equal mass fly off south and west, perpendicular to each other, at \( 18 \) \( \text{m/s} \). The third piece has \( 2.5 \) times the mass as the other two.

Intermediate
Mathematical
GQ

If the coefficient of static friction is \( \mu_s = 0.5 \), how much force must be applied to a spring (spring constant of \( 0.8 \) \( \text{N/m} \)) which is attached to a block of wood (mass \( 4.0 \) \( \text{kg} \)) in order to just begin to move the block?

Advanced
Conceptual
MCQ

A fisherman is standing in the back of his small fishing boat (the mass of the fisherman is the same as the mass of the boat) and he is a few meters from shore. He is done fishing so he starts walking towards the shore so he can get off the boat. What happens to the boat and the fisherman? Select all that apply and assume there is no friction between the boat and the water.

Intermediate
Conceptual
MCQ

Which statements are not valid for a projectile? Take up as positive.

Intermediate
Mathematical
FRQ
A right-triangle ramp is drawn on the left side of a horizontal baseline. The ramp’s hypotenuse slopes downward from left to right at an angle labeled “θ0” between the hypotenuse and the rightward horizontal baseline. The horizontal run of the ramp (its base) is marked as length D, starting at x = –D on the leftmost top point of the ramp and ending at x = 0 at the foot of the ramp. From x = 0 to x = 4D, the baseline is a straight horizontal line representing the rough surface. Tick marks on the baseline indicate positions x = 0, D, 2D, 3D, and 4D. The inclined segment is frictionless; the horizontal segment is shaded or marked as rough. No block is explicitly drawn on the diagram.

A block is initially at rest on top of an inclined ramp that makes an angle \( \theta_0 \) with the horizontal. The distance measured along the base of the ramp is \( D \). After the block is released from rest, it slides down the frictionless ramp and then continues onto a rough horizontal surface until it finally comes to rest at the position \( x = 4D \) measured from the base of the ramp. The coefficient of kinetic friction between the block and the rough horizontal surface is \( \mu_k \).

Intermediate
Mathematical
GQ

A mine shaft is known to be 57.8 m deep. If you dropped a rock down the shaft, how long would it take for you to hear the sound of the rock hitting the bottom of the shaft knowing that sound travels at a constant velocity of 345 m/s?

Beginner
Conceptual
GQ

Suppose just two external forces act on a stationary, rigid object and the two forces are equal in magnitude and opposite in direction. Under what condition does the object start to rotate?

Beginner
Conceptual
GQ

Are astronauts really “weightless” while in orbit?

Intermediate
Conceptual
MCQ

Two forces produce equal torques on a door about the door hinge. The first force is applied at the midpoint of the door; the second force is applied at the doorknob. Both forces are applied perpendicular to the door. Which force has a greater magnitude?

Intermediate
Mathematical
FRQ

nerd notes ubq 103999

A uniform rod of length \( L \) and mass \( M \) is free to rotate about one end, as shown in the diagram. The free end is released from rest at a horizontal position, as shown. The pivot point is supported by a stand so that only the free end can move. The moment of inertia of a rod about its end is \(\tfrac{1}{3} M L^{2}\).

Beginner
Mathematical
GQ

A 1100 kg car accelerates from 32 m/s to 8.0 m/s in 4.0 sec. What amount of force was needed to slow it down?

Intermediate
Mathematical
MCQ

When the mass of a simple pendulum is tripled, the time required for one complete vibration

Beginner
Mathematical
MCQ

An object’s angular momentum changes by \( 10 \,\text{kg} \cdot \text{m}^2/\text{s} \) in \( 2.0 \) \( \text{s} \). What magnitude average torque acted on this object?

Intermediate
Conceptual
MCQ

One end of a string is wrapped around a pulley that is free to rotate with negligible friction about an axle at its center. The other end of the string is attached to a block. The block is released from rest and moves downward with constant acceleration. Which of the following correctly indicates whether the amount of work done on the pulley by the string during each successive complete rotation remains constant or increases, and provides a valid justification?

Advanced
Conceptual
FRQ

A student is watching their hockey puck slide up and down an incline. They give the puck a quick push along a frictionless table, and it slides up a \( 30^\circ \) rough incline (\( \mu_k = 0.4 \)) of distance \( d \), with an initial speed of \( 5 \) \( \text{m/s} \), and then it slides back down.

Beginner
Mathematical
GQ

A disk increases from 2 complete revolutions in 2 seconds to 5 complete revolutions in 2 seconds. What is its average angular acceleration?

Intermediate
Mathematical
GQ

A woman stands on a bathroom scale in a motionless elevator. When the elevator begins to move, the scale briefly reads only \( 0.75 \) of her regular weight. Calculate the acceleration of the elevator, and find the direction of acceleration.

Intermediate
Mathematical
GQ

Person A throws a ball horizontally from a cliff \( 20 \) \( \text{m} \) tall at \( 12 \) \( \text{m/s} \). Person B is running to the right on the ground and catches the ball at the same height it would’ve landed after running \( 15 \) \( \text{m} \). How fast was Person B running?

Beginner
Mathematical
GQ

A stone is thrown horizontally at \(8.0 \, \text{m/s}\) from a cliff \(80 \,\text{m}\) high. How far from the base of the cliff will the stone strike the ground?

Advanced
Mathematical
FRQ

A snowboarder starts from rest and slides down a \(32^\circ\) incline that’s \(75 \, \text{m}\) long.

Advanced
Mathematical
GQ

A space probe far from the Earth is traveling at 14.8 km/s. It has mass 1312 kg. The probe fires its rockets to give a constant thrust of 156 kN for 220 seconds. It accelerates in the same direction as its initial velocity. In this time it burns 150 kg of fuel. Calculate final speed of the space probe in km/s.

Note: This is a bonus question. Skip if you haven’t yet taken calculus.
